The RØDELink Filmmaker Kit provides everything you need to start shooting video wirelessly, including a receiver, transmitter & broadcast-grade lavalier microphone. The receiver (RX-CAM) features an OLED display with information on level, battery status (receiver & transmitter), mute & channel selection. The unit can be mounted on a st&ard camera shoe mount, 3/8" thread or belt-clip, & for added versatility the shoe mount can be located in one of two positions.
The lightweight transmitter (TX-BELT) can be fitted to a belt or clothing & features a locking thread to ensure the microphone connection is as secure as possible. RØDE has included an omnidirectional lavalier microphone in the kit to provide the highest possible audio reproduction quality.
FEATURES
- Series II, 2.4GHz digital transmission
- 128-bit encryption
- Up to 100 metres range*
- OLED display (on receiver)
- One button pairing
- Three level gain control
- AA battery or USB powered
- Includes broadcast lavalier microphone
RØDELink Filmmaker Kit
- Transmission type: 2.4GHz Fixed Frequency Agile System
- Frequency range: 35Hz - 22kHz
- System dynamic range: 112dB
- Range (distance): Up To 100m
- Maximum output level: 1v Rms (2.8v P-p)
- Max input signal level: 1v Rms (2.8v P-p)
- Max latency: 4ms
Receiver (RX-CAM)
- Power source: 2 X AA Battery Or MicroUSB
- Antenna: Internal
- Output connection: 3.5mm TRS Locking Jack Socket - Dual Mono
- Output impedance: 300?
Transmitter (TX-BELT)
- Power source: 2 X AA Battery Or MicroUSB
- Antenna: Internal
- Input connection: 3.5mm TRS Locking Jack Socket
- Input impedance: 10k?
Lavalier
- Acoustic Principle: Permanently Polarized
- Frequency Range: 60Hz - 18kHz
- Output Impedance: 3000?
- Maximum SPL: 110dB SPL (@ 1kHz, 1% THD into 1K? load)
- Maximum Output Level: 189.0mV
- Sensitivity: -33.5dB re 1 Volt/Pascal (21.00mV @ 94 dB SPL) +/- 2 dB @ 1kHz
