AiX Sound Source delivers High Quality Tones and Rich Expressiveness

The CT-X Series comes with the AiX Sound Source, which can produce a wide range of sound qualities from powerful bass tones to clear high tones. The exceptional computing power of the high performance LSI reproduces the natural charm of acoustic instrument sounds, such as the agreeable change in tone when a piano key is struck, the sensation of a drum performance, or soaring strings.

The high-speed digital signal processor is also applied for each sound type, such as melody, backing drum and bass, or organ. Even the standard ensemble for a keyboard delivers distinct sound for each instrument for an expressive performance.

High-Visibility, Useful LCD Screen with Backlit

Conveniently displays helpful information for performances or lessons. Backlit for great visibility.

Touch Response for Expressive Performance (Touch Sensitive Keyboard)

Look forward to expressive performances with sound levels that vary with the strength with which a key is pressed, just like a real piano.

Piano Keyboard for Responsive Performance

The keyboard features piano keys for easy learning and realistic experience of performing.

• The keyboard has box keys. (Size of white keys: Length approx. 136 mm × width approx. 22 mm)

Look Forward to Playing Exactly As You Want With Ease

Arpeggiator

Automatically play arpeggios and phrases just by pressing keys. Built-in phrases such as guitar arpeggios and stroke playing, or ones suitable for bass or synthesizer style performances.

Auto-accompaniment

Drums, bass and other accompaniment plays when a chord is played with the left hand, so even beginners can enjoy playing as if with a band or orchestra.

Confirm Chords Easily with the Chord Book

The keyboard includes a chord dictionary. Select a chord name and the LCD monitor will show what notes make it up and how to play it on the keyboard - you can even hear what it sounds like.

Auto Harmonize

Automatically adds harmony to melodies played, making it easy to hold performances with the depth that comes from a professional musician.

Registration

Register detailed setups such as favorite tones, rhythms and tempos all in one go. Load them instantly when you need them, and it’s easy to change settings mid-performance.

Music Presets

Setups (tone, rhythm, etc.) for songs from a wide range of genres are available as presets. Just load one to create the performance you want.

Pitch Bend Wheel

The pitch bender wheel makes it easy to add realistic sounding guitar choking, sax bending, and other effects to keyboard play.

Lesson System for Solid Improvement

Step Up Lessons

Lessons for short, easy to remember musical phrases. Learn one phrase, then move on to the next, working through them until the whole song is mastered.

Grading and Voice Instruction

The LCD screen shows a grade for the performance. And if you’re stuck during a performance, a voice prompt will say which finger to use.

• Finger positioning is only available for right hand or left hand lessons.

Lesson Part Selection (Right hand, left hand, both hands)

Lessons are available for each part, with lessons for the left hand, right hand, and both hands.

Metronome

160 Track Song Bank

Audio Input Port to Play Along With Your Favorite Songs

Use the keyboard as a playback device by connecting an audio player such as a digital audio player or CD player, and play along.

Connect to a Computer to Enjoy Even More Songs On Your Keyboard!

The keyboard has a USB port* for easy connection to a computer. Up to 10 tracks can be saved to the keyboard in addition to the built in tracks.

• Compatible with the following OS: Windows® Vista (32-bit), Windows® 7 (32-bit, 64-bit), Windows® 8.1 (32-bit, 64-bit), Windows® 10 (32-bit, 64-bit), Mac® OS (10.7 or higher)

Keyboard

• 61 standard size keys
• Touch Response: Sensitivity 3 types, Off

Maximum Polyphony: 48 notes (24 for certain tones)

Tones

• Built-in Tones: 600
• Functions: Layer, Split, Piano/Organ button

Reverb: 1 to 20, Off

Chorus: 1 to 10, Tone

Metronome

• Beats per Measure: 0 to 9
• Tempo Range: 20 to 255

Song Bank

• Demo Song: 1
• Built-in Songs: 160
• User Songs: 10*
• User-recorded songs: 6*
• * Maximum capacity per song: Approximately 320 kilobytes

Step Up Lesson

• Lessons: 3 (Listen, Watch, Remember), Easy Mode
• Lesson Part: L, R, LR
• Functions: Repeat, Voice Fingering Guide, Note Guide, Performance Evaluation

Auto Accompaniment

• Built-in Rhythms: 195
• User Rhythms: 10*
• * Maximum capacity per rhythm: Approximately 64 kilobytes

Chord Book Function: Chord guide

Registration: 32 (4 setups x 8 banks)

Recorder

• Real-time recording, playback
• Keyboard Play: 5 songs, 6 tracks
• Playing Along with a Built-in Songs: 1 song (L, R, LR)
• Memory Capacity: Approximately 40,000 notes (1 song)

Other Functions

• Transpose: ±1 octaves (-12 to +12 semitones)
• Octave Shift: Upper 1/Upper 2/Lower, ±3 octaves
• Tuning: A4 = 415.5 to 465.9 Hz (Initial Default: 440.0 Hz)
• Preset Scales: 17
• Music Preset: 310
• One Touch Preset: 195
• Auto Harmonize: 12 types
• Arpeggiator: 100 types

MIDI: 16 multi-timbre received, GM Level 1 standard

Musical Information Function: Tone, Rhythm, Song Bank numbers and names, staff notation, fingering, pedal operation, tempo, measure and beat number, chord name, etc.

Pitch Bend Wheel: Pitch Bend Range 0 to 24 semitones

USB Flash Drive: SMF direct playback, data storage, data loading, data deleting, USB flash drive format

Inputs/Outputs

• USB flash drive port: TYPE A
• USB port: TYPE B
• PEDAL jack: Standard jack (sustain, sostenuto, soft, rhythm) Phones/Output jack: Stereo standard jack/Output Impedance 167Ω, Output Voltage 4.5V (RMS) MAX
• Audio In jack: Stereo mini jack/Input Impedance 10kΩ, Input Sensitivity 200mV

Power Jack: DC 9.5V

Power Supply

• 2-way
• Batteries: 6 AA-size alkaline batteries
• AC Adaptor: LAD-6 Adaptor

Speakers: 12cm x 2 (Output: 2.5W + 2.5W)

Power Consumption 7.5 W

Dimensions W 94.8 x D 35.0 x H 10.9 cm
